RWT-FC90-30M*
Product parameters

Technical Specification:

Max. Operating pressure：

3000 bar

Max. Flow rate：

117 l/min

Rotation speed：

approx. 200~1500rpm

Max. Outer diameter：

ø90mm

Connection thread：

1-1/8-12 UNF Female seal with 60-degree cone or custom-made
adapter provided


RWT-FC90-30M3

With three M10*1.5  sapphire nozzles screwed in nozzle extensions "T"

and  back jets.


RWT-FC90-30M4

With four  M10*1.5  sapphire  nozzles  screwed in nozzle extensions "T"

Two at 90 degrees, two back jets.


RWT-FC90-30M6

With total six  M10*1.5  sapphire  nozzles  screwed  in  nozzle  head  or nozzles extensions "S".  Two forward jets,  two at 90 degrees, two back jets.


RWT-FC90-30M7

With total seven sapphire nozzles screwed in nozzle head.

Three 1/4-28  nozzles forward jets , two M10*1.5 nozzles at 90 degrees, two M10*1.5 nozzles back jets.
